John Deere ZF MT–S 3085 FRONT AXLE Component Technical Service Repair Manual CTM366 - PDF

Stay up-to-date with the John Deere ZF MT–S 3085 FRONT AXLE Component Technical Service Repair Manual CTM366 - PDF. This manual provides detailed instructions for the diagnosis and repair of your John Deere front axle and is designed to provide professional mechanics with the exact information they need to perform maintenance and repairs. Keep your John Deere running at peak performance with this comprehensive service repair manual.

This official John Deere ZF MT–S 3085 Front Axle Component Technical Service Repair Manual (CTM366) provides detailed service information, step-by-step repair instruction and maintenance specifications for your John Deere Front Axle Component. Get all the guidance you need to safely and efficiently repair, service, and maintain your tractor.

Models Covered:
ZF MT–S 3085 AXLE (TRUNNION MOUNT)

Manual Contents:
Preface
General
Examples of Contact Pattern for the Gleason Gear-Tooth System
Lubrication and Maintenance Instructions
Wear Measurement – Multi-Disc Brake
Inscription on Model Identification Plate and Specifications for Spare Parts Orders
Conversion Table for Dimensional Units
Denomination of Standard Dimensions
Torque Limits for Screws

List of Tools (required Special Tools)
Illustrated Tables

1. Disassembly of Output and Brake
2. Reassembly of Output and Brake
3. Disassembly of Bearing Supports, Axle Insert (Type: DK) and Oil Pipes
3.1 Disassembly of Bearing Supports
3.1.1 Disassembly of Input-sided Bearing Support
3.1.2 Disassembly of Rearside Bearing Support
3.2 Separate Outputs from the Axle Casing
3.2.1 Separate Output (LH) from the Axle Casing
3.2.2 Separate Output (RH) from the Axle Casing
3.3 Disassembly of 100% – Differential Lock
3.4 Disassembly of Axle Insert
3.4.1 Disassembly of Limited-Slip Differential (D-1600)
3.4.2 Disassembly of Locking Differential (DHK-2400/DVK)
3.4.3 Disassembly of Drive Pinion
3.5 Disassembly of Oil Pipes

4. Reassembly of Oil Pipes, Axle Insert (Type: DK) and Bearing Supports
4.1 Reassembly of Oil Pipes
4.2 Reassembly of Axle Insert
4.2.1 Determine Shim Thickness for a Perfect Tooth Contact Pattern
4.2.2 Install the Drive Pinion
4.2.3 Reassembly of Limited-Slip Differential (D-1600)
4.2.4 Reassembly of Locking Differential (DHK-2400/DVK)
4.2.5 Adjust the Backlash, Bearing Rolling Moment and Bracket Width
4.3 Reassembly of 100% – Differential Lock
4.4 Mount Outputs to the Axle Casing
4.4.1 Mount the Output (RH)
4.4.2 Mount the Output (LH)
4.5 Reassembly of Bearing Supports
4.5.1 Reassembly of Rearside Bearing Support
4.5.2 Reassembly of Input-sided Bearing Support

Total Pages: 114
Configuration: PDF File
Language Type: English
Clarification: Illustration Diagrams
Approachable: Always
You Can Immediately Download After Purchase.
Remarkable Assistance: 24×7
Cooperative With All Versions Of Windows, Mac, iOS, Android
